K-45TPG4 SPECIFICATIONS
Length: 316mm( 12.44" )
Weight: 1800g ( 3 lb. 15.5 oz )
Max. RPM: up to 170000
Power: 5.2KW EGT: 700°C max ( 1292°F max)
Fuel consumption: 180 g / min ( 8.46 oz / min )
Fuel: Diesel, Jet A1, Kerosene
Lubrication: 5%
Maintenance cycle: 25 hr US$550
Recommended Propeller: 22 x 12 x 3B
Thrust: 20kg
KingTech G4 utilizes SBus data transmission.
Engine/ECU integration, all operating parameters including total run time are all recorded into the engine.
The smaller and lighter external Data Relay Module (DRM) is responsible for all data, signal and power transmission.
A micro USB connector is present for a future connectivity of wireless mobile apps.
The G4 features a brushless starter motor for reliability and durability, built-in FOD screen is also integrated.
After a run cycle and receiver switched off, GSU will remain on only until cool down completes.
